Gravity Conveyor Models
Gravity Conveyors
Model | Roller Diameter | Roller Tube Gauge | Hex Axle | Frame Depth | Frame Gauge | Roller Rating |
Model 901 | 1-3/8” | 18 | 5/16 | 2-1/2” x 1” | 12 | 100# |
Model 910 | 2” | 16 | 7/16 | 3-1/2” x 1-1/4” | 10 | 240# |
Model 911 | 2” | 13 | 7/16 | 3-1/2” x 1-1/4” | 10 | 280# |
Model 920 | 2-1/2” | 11 | 11/16 | 4 x 5.4#- channel frame | 4 x 5.4#- channel frame | 600# |
Model 921 | 2-5/8” | 7 | 11/16 | 4 x 5.4#- channel frame | 4 x 5.4#- channel frame | 650# |
Model 950 | 3-1/2” | .300 wall pipe | 1-1/16 | 6 x 8.2#- channel frame | 6 x 8.2#- channel frame | 2,000# |
